Designed for professionals that push boundaries with the quality of their videos, this 7-inch screen elevates the image captured by any HDMI or SDI camera to new levels. With 1,000,000:1 contrast ratio and peak brightness of 3000nits, Shogun 7 is the ultimate all-in-one video production tool.

Shogun 7 embraces the high production values of RAW and 4K HDR to give you complete control of every aspect of your production, on-set and in post. Meticulously monitor every pixel of SDR or HDR as it’s captured. Record up to 5.7K Apple ProRes RAW* or 4K Apple ProRes. You can even shoot RAW at high frame rates up to HDp240**.

*Panasonic EVA1 **Sony FS Series and EVA1

Blackmagic Design’s Hyperdeck Studio HD Plus is a compact video file recorder with an extended feature set. With h.264, ProRes, and DNx formats available for recording, you can choose between file size and fidelity to match your postproduction workflow. Two high speed UHS-II SD Card slots allow extended roll-over recording on the front, or choose to record to a high capacity drive using the rear USB-C port. Files can be quickly dumped from the SD Cards with the included UHS-II to USB-C high speed dock, or clips can be pulled off the unit over network using FTP.

Hybrid events can use the Hyperdeck Studio HD Plus for double duty, recording on SD Card while capturing the video by USB-C as a 1080p webcam input to a video call. Quickly monitor the audio using the front panel speaker, or listen carefully via the front panel headphone jack. The SDI Monitoring output can also provide overlays including audio level, recording time remaining and drive status, and more.

Hyperdeck Studio HD Plus can also be used in a video file playback role, controlled from the front panel or by network. ProRes 4444 files with Alpha channel can be played as Key and Fill from the 2 6G-SDI output connectors. There is tight integration for playback when used with ATEM switchers.

Genlock Sync and Timecode can be provided to the Hyperdeck in Multicam environments, or choose to follow the input timing (for genlock) and time of day for timecode. If internally generated, this timecode is provided on the LTC Timecode output, so one unit can be used to provide timecode to the others if a master timecode device is not on site.

This well-rounded feature set provides a lot of flexibility in the field in a very portable size.

The Atomos Shogun Flame is a 7″, 1920 x 1200 on-camera recording monitor that combines 4K recording with a 10-bit FRC panel that supports native display of HDR (log) footage as well as high brightness viewing of Rec. 709 footage. It utilizes 4K HDMI and 12G-SDI inputs to support clean output signals at resolutions up to UHD 4K (3840 x 2160), recording it to 2.5″ SSDs using 10-bit, 4:2:2 Apple ProRes and Avid DNxHR codecs. It even supports DCI 4K (4096 x 2160) raw video streams over SDI from select Sony and Canon cameras, encoding it as ProRes/DNxHR files.

The monitor features 10-bit FRC processing and AtomHDR display technology support a 10-stop brightness range, allowing you to more accurately monitor your log gamma footage without having to view flat, washed-out looking images or use a LUT to compress the dynamic range and color space. The monitor offers built-in pre-sets to accurately translate popular log formats from Sony, Canon, Panasonic, ARRI, RED, and JVC cameras. The settings only affect viewing, with recorded video remained unaltered.

In addition to HDR monitoring, the monitor also offers a High Bright mode for traditional Rec. 709 monitoring. This mode takes advantage of the full 1500 cd/m² brightness to allow for more confident monitoring in bright outdoor environments, even without a sun hood. In HDR mode, use of an included snap-on sun hood is required, as displaying a wider brightness range reduces the overall brightness of the monitor.
