Roland V-1SDI

3G-SDI Video Switcher

Roland V-1SDI for rent

Roland V-1SDI for rent


Roland V-1SDI for rent


Roland V-1SDI for rent


Mouse roll-over to zoom image.

Product Highlights

Support for SDI and HDMI cameras, smartphones, tablet computers, PC’s, etc.
Supports up to Full HD 1080p
3 x SDI Inputs, 2 x HDMI Inputs
Quad input multi-viewer with source labeling and audio metering
HDCP Compliant

Rentex No. SWROLV1S | Mfr No. V-1SDI

Roland’s V-1SDI Video Switcher is a flexible and versatile video switcher that makes it easy to connect and switch professional 3G SDI cameras and playback sources along with HDMI sources including cameras, smart phones, computers, tablets, Blu-ray players. Compact and portable, the V-1SDI delivers professional switching results with its easy to use hardware interface complete with T-Fader and easy-to-see backlit buttons. With support for 3G-SDI, the V-1SDI can operate at full 1080p resolution and can take advantage of the longer cable distance of SDI making this compact solution suitable for events and applications in even large spaces with the most professional level of SDI camera sources.

Roland V-1SDI Owner's Manual

Roland V-1SDI Spec Sheet from Rentex

Processing

Video Processing	8-bit 4:2:2 (YPbPr)
Audio Processing	24-bit at 48 kHz

Input Signal Formats

SDI

Inputs 1 to 3
1080p: 59.94/50
1080i: 59.94/50
720p: 59.94/50Conforms to SMPTE 424M (SMPTE 425M-AB), 292M, 259M-C

HDMI

Input 3
1080p: 59.94/50
1080i: 59.94/50
720p: 59.94/50HDCP supported

Input 4
1080p: 59.94/50
1080i: 59.94/50
720p: 59.94/50
480p: 59.94
576p: 50
480i: 59.94
576i: 50
WUXGA: 1920 x 1200 @ 60 Hz
UXGA: 1600 x 1200 @ 60 Hz
SXGA+: 1400 x 1050 @ 60 Hz
FWXGA: 1366 x 768 @ 60 Hz
SXGA: 1280 x 1024 @ 60 Hz
WXGA: 1280 x 768 @ 60 Hz
XGA: 1024 x 768 @ 60 Hz
SVGA: 800 x 600 @ 60 Hz
VGA: 640 x 480 @ 60 Hz

HDCP supported

Output Signal Formats

Program & Preview Output	SDI 1080p: 59.94/50 1080i: 59.94/50 720p: 59.94/50Conforms to SMPTE 424M (SMPTE 425M-AB), 292M, 259M-C
MultiView	HDMI HDCP supported
Input Level	Audio In: -10 dBu (Maximum: +8 dBu) Mic: -41 to -13 dBu (Maximum: -1 dBu)
Output Level	Audio Out: -10 dBu (Maximum: +8 dBu) Phones: 92 mW + 92 mW (32 Ohms)

Connectors

Input	Video 3 x SDI, BNC 2 x HDMI Type-AAudio Analog: RCA phono Mic: Stereo mini jack
Output	Program 1 x SDI, BNCPreview 1 x SDI, BNC Multiview 1 x HDMI Type-A Audio Analog: RCA phono Headphones: Stereo mini jack
Remote	USB Type-B (for remote control from PC) RS-232: DB-9
Audio Impedance	Input Audio: 15 kOhms Mic: 10 kOhmsOutput Audio: 1 kOhms Phones: 10 Ohms

General

Power Supply (AC)	AC adapter
Current Draw	2.1 A
Power Consumption	25 W
Operating Temperature	32 to 104°F / 0 to 40°C
Dimensions (H x W x D)	12.3 x 4.3 x 2.3″ / 31.3 x 10.8 x 5.9 cm
Weight	2.6 lb / 1.2 kg (excluding AC adapter)
