QSC K10
10" 2-Way Active Loudspeaker
Product Highlights
- 10” Woofer; 1.75” diaphragm compression driver
- 1000-watt continuous Class D power modules in all models
- 90° conical DMT coverage
- Maximum SPL 129 dB peak
- Attractive and professional appearance | Rugged ABS enclosures
The QSC K Series is quite simply The New Standard in lightweight powered loudspeaker systems. For starters, each of the four models features an all new, Pat Quilter designed 1000 watt continuous QSC Class D power module. Next, breaking from the traditional loudspeaker paradigm, every model is fitted with the identical 1.75″ HF device (full-range models) and woofers of the same high quality for unparalleled performance, regardless of speaker size.
| SPECIFICATIONS | Â | Â | Â | Â | Â | K10 | |
| Configuration | Multipurpose 2-way | ||||||
| Transducers Low-frequency High-frequency | 10″ cone transducer 1.75″ diaphragm compression driver | ||||||
| Frequency Response (-6 dB) | 60 Hz – 18 kHz | ||||||
| Frequency Range (-10 dB) | 56 Hz – 20 kHz | ||||||
| Nominal Coverage (-6 dB) | 90° conical DMT | ||||||
| Maximum SPL1 | 129 dB peak | ||||||
| Â | Â | Â | Â | Â | Amplifiers | ||
| Power Output2 | 1000 W continuous Class D (500 W LF, 500 W HF) 2000 W peak | ||||||
| Input Impedance | XLR / ÂĽ”: 40 kΩ balanced / 20 kΩ unbalanced XLR / ÂĽ” MIC mode: 2260Ω balanced RCA: 10 kΩ | ||||||
| Controls | Power, Gain A, Gain B, Mic/Line, LF Mode (Ext Sub/Norm/DEEP™), HF Mode (Flat/Vocal Boost), Front LED (On/Off/Limit) | ||||||
| Indicators | Power, Signal A, Signal B, Standby, Limit, Mic | ||||||
| Connectors | Balanced female XLR/ÂĽ” line/mic level input, Balanced female XLR/ÂĽ” line level input, Dual Balanced male XLR full range line level out , Balanced male XLR “mix” out, Stereo RCA line level input, Remote gain control, Locking IEC power connector | ||||||
| Cooling | On demand, 50 mm variable speed fan | ||||||
| Amplifier Protection | Thermal limiting, output overcurrent, overtemperature muting, GuardRail™ | ||||||
| Transducer Protection | Thermal limiting, excursion limiting | ||||||
| AC Power Input | Universal power supply 100–240 VAC, 50 to 60 Hz | ||||||
| AC Power Consumption (1/8 of full power) | 100 VAC, 2.3 A 120 VAC, 2.01 A 230 VAC, 1.13 A | ||||||
| Â | Â | Â | Â | Â | Enclosure | ||
| Material | Impact resistant ABS | ||||||
| Finish | Black paint | ||||||
| Grille | Rugged powder-coated steel | ||||||
| Dimensions (HWD) in | 20.4 Ă— 12.6 Ă— 11.8 | ||||||
| Dimensions (HWD) mm | 519 x 320 x 300 | ||||||
| Weight (Net) | 32 lb / 14.5 kg | ||||||
-
