Compact Form-Factor

The PT-RQ25K is 40% smaller and 35% lighter than the previous generation of the trusted 20K Panasonic 3-DLP projectors and the PT-RZ21K/RQ22K. In fact, the size is much closer to the PT-DZ10KU that gave us just 10,000 lumens a few years ago. That size and weight advantage provides a wide impact on case size, shipping cost, and how this powerhouse can be used. New features for the platform include the Smart Projector Control smartphone app with NFC function, Remote Preview Lite, and as with ALL Rentex Panasonic 3-DLP projectors, the Geometry Manager Pro license is included.

Engaging Visual Experience

Quad Pixel Drive creates smooth 4K images with vivid 3-Chip DLP color and high brightness. A new Dynamic Contrast setting delivers higher white brightness and deep blacks during high-contrast scenes. Gradation Smoother reduces color-banding while improved point-based black-level adjustment supports edge-blending over curved screens with pixel-level precision.

Reliable and Maintenance-free

A hermetically sealed optical block is cooled by a high-efficiency liquid-cooling system enabling maintenance-free projection for 20,000 hours. Multi-Laser Drive Engine prevents brightness loss in the event of diode failure, while Backup Input switches to a backup signal if the primary signal is interrupted for peace of mind.

3-Chip DLP™ projector

20.3 mm (0.8 in) diagonal (16:10 aspect ratio) DLP™ chip x 3, DLP™ projection system 2,304,000 (1920 x 1200 pixels) x 3

Laser diode 20,000 Im/ 21,000 Im (Center)

20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)

1920×1200 native resolution. 5120×3200 when quad pixel drive on.

25,000:1 (Full On/Full Off, Dynamic Contrast [3])

1.78-25.40 m (70-1000 in), 1.78-15.24 m (70-600 in) with ET-D75LE8/ ET-D3LET80, 3.05-15.24 m
(120-600 in) with ET-D75LE95, 5.08-15.24 m (200-600 in) with ET-D3LEU100/D3LEW200

HDMI x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal inputs) DisplayPort™ x 1 (Deep Color, compatible with HDCP 2.3, 4K/60p signal inputs)

AC 100 V-120 V / AC 200 V-240 V, 50 Hz/60 Hz (The maximum value of light output is limited to 15,000 Im or less when using the projector with AC 100 V to AC 120 V.)

AC 200 V-AC 240 V: 1,490 W {1,520 VA)

AC 100 V-AC 120 V: 1,080 W {1,090 VA)

Risk group 3. 54.0 kg (119 lbs) without cage.

Digital link, quad 3g SDI, equippped with optional 2x HDMI input board ET-MDNHM10. Output reduced to 12k.

Weight: 83 kg (183 lbs.) without cage, 98 kg (216 lbs.) with cage
