Barco PDS-902

Digital Switcher

Mouse roll-over to zoom image.

Product Highlights

10-bit sampling and processing
High-quality scaling technology
Auxiliary control from Encore and ScreenPRO-II controllers
Fast and seamless switching
I/O: (4) VGA, (4) DVI, (1) 3G SDI, (1) Program Output, (1) Preview Output

Rentex No. SWPDS902 | Mfr No. R9004688

The PDS-902 features four DVI-I inputs with full HDCP 1.0 support, one 3G/HD/SD SDI, and four universal analog inputs. All analog and DVI inputs support the EDID 1.3 specification. Users can capture and store up to three images that can be used as a LOGO source during the presentation. In addition to the program output, the PDS-902 offers a preview with the same or different resolution than the program output. Users have the option of displaying 1 of 3 signals on the preview output: program, preview or test pattern.

Rentex Spec R9004688

(1) BARCO PDS-902 Switcher
(2) VGA(F) to DVI-I(M) ADAPTER
(2) VGA(M) to 5-WIRE(BNC) BREAKOUT
(2) 6′ VGA (M-M) CABLE
(2) 6′ DVI-I (M-M) CABLE
(1) MANUAL
(1) POWER CORD/POWER SUPPLY
(1) Quick Start Guide
(1) 10′ CAT 5 CABLE

Video Inputs	DVI-I Digital formats: All single-link DVI digital formats up to 165 MHz, per DVI 1.0 specification Analog formats: NTSC/PAL composite and Y/C video, SD YPbPR with bi-level sync, HD YPbPr with tri-level sync, RGBHV/RGBS/RGsB computer video with bi-level sync Analog 1:1 sampling up to 1920 x 1080 @ 60 Hz. Sources with native pixel rates greater than 150 MHz will be filtered and sampled at 150 MHz. These include but not limited to 1920 x 1080p @ 60 (173 MHz), 1920 x 1200 @ 60 (193.25 MHz) and 2048 x 1080p @ 60 (183.75 MHz) EDID version 1.3 compatible – HDCP version 1.0 compatible HD-15 VGA Format: NTSC/PAL composite and Y/C video SD YPbPr with bi-level sync HD YPbPr with tri-level sync per SMPTE 274, RGBHV/RGBS/RGsB computer video with bi-level sync Analog 1:1 sampling up to 1920 x 1080 @ 60 Hz. Sources with native pixel rates greater than 150 MHz will be filtered and sampled at 150 MHz. These include but not limited to 1920 x 1080p @ 60 (173 MHz), 1920 x 1200 @ 60 (193.25 MHz) and 2048 x 1080p @ 60 (183.75 MHz) EDID version 1.3 compatible SD/HD/3G SDI on BNC Formats: SD-SDI per SMPTE 259M-C (NTSC/PAL resolution); HD-SDI per SMPTE 292M, 296M; 3G-SDI per SMPTE 424M
Video Outputs	DVI-I Formats: All single-link DVI digital formats up to 165 MHz, per DVI 1.0 specification EDID version 1.3 compatible – HDCP version 1.0 compatible HD-15 VGA Formats: HD YPbPr with tri-level sync per SMPTE 274, RGBHV/RGBS/RGsB computer video with bi-level sync EDID version 1.3 compatible
Control	Ethernet RJ-45, 10/100 Mbps autosense Computer, tablet, smartphone, or Encore, or ScreenPRO-II Controller via Ethernet link
Input Power	100 to 240 VAC, 47 to 63 Hz, auto-selecting 2.0 A maximum
Temperature	32 to 104°F (0 to 40°C)
Humidity	0 to 95% non-condensing
Height	1 RU Rack Mount: 1.75″ (4.44 cm
Width	Without Chassis Handles: 17.00″ (43.18 cm) With Chassis Handles Attached: 19.06″ (48.41 cm)
Depth	From Front to Rear Panel: 14.25″ (36.19 cm)
Weight	12.5 lb (5.6 kg)
